| Ingrandisci immagine |
Prezzo: € 999,00 +IVA
Disponibilità: 0
Specification
CPU
Intel Socket 775 Processors
Chipset
Intel G31 / Intel ICH7
Front Side Bus
1600*/1333/1066/800 MHz *overclock speed
Memory
4 x240-pin DIMM, Max. 4 GB, DDR2 1066*/800/667 Non-ECC,Un-buffered Memory
Dual Channel memory architecture
Expansion Slots
2 x PCIe x16 (blue @ x16 mode,black @ x4 or x1 mode), featuring CrossFireX technology
3 x PCI
CrossFire
ATI CrossFire X Technology
Storage
Southbridge
1 xUltraDMA 100/66
4 xSATA 3 Gb/s ports
LAN
Realtek 8110SC Gigabit LAN controller
Audio
VIA VT1708B 8 -Channel High-Definition Audio CODEC
Audio Jack-detect & Multi-Streaming
Support S/PDIF Out connector
USB
8 USB 2.0 ports
Overclocking Features
SFS (Stepless Frequency Selection) from 200MHz to 600MHz at 1MHz increment
ASUS C.P.R.(CPU Parameter Recall)
Special Features
ASUS MyLogo 2
ASUS EZ Flash 2
ASUS CrashFree BIOS 3
ASUS Q-Fan
Back Panel I/O Ports
1 x PS/2 Mouse
1 x PS/2 Keyboard
1 x LPT
1 x COM
1 x Optical S/PDIF outport
1 x LAN(RJ45)
4 x USB 2.0/1.1
8-channel Audio I/O
Internal I/O Connectors
1 x Azalia High definition Analog Front panel Audio connector
1 x S/PDIF output connector
1 x Chassis Intrusion connector
1 x System Panel connector
4 x USB 2.0 connectors support additional 8 USB 2.0 ports
1 x CPU/ 1 x Chassis/1 x Power FAN connectors
1 x CD audio in connector
1 x Floppy disk drive connector
1 x IDE connector
1 x 24-pin EPS12V Power connector
1 x 4-pin ATX 12V Power connector
BIOS
8 Mb Flash ROM
Special H/W write protection
DMI 2.0
AMI BIOS
PnP
WfM 2.0
SM BIOS 2.5
ACPI 2.0a
Manageability
WOL by PME,WOR by PME, WOR by Ring
O/S Compatibility
Windows Vista
Windows XP
Accessories
2 x Serial ATA cables
1 x 2 in 1 Serial ATA power cable
1 x UltraDMA 100/66 cable
1 x FDD cable
1 x I/O shield
User manual
Support Disc
Drivers
ASUS PC Probe II
ASUS LiveUpdate Utility
Form Factor
ATX Form Factor
12 inch x 9 inch ( 30.5 cm x 22.9 cm )
